GATES Plant Master 300 EPDM
    • 产品详细PDF下载：

    规格参数

    • 产品编号： 3204-5661 型号： 3/4
      内径 mm： 19 工作压力bar： 21
      价格 元/个： 型号 米/卷：

    产品简介

    颜色：黑/蓝/绿/红/黄
    温度：-40~+93
    软管用途：

    产品详情

    RECOMMENDED FOR: Air and water applications requiring maximum flexibility in any industry, including mining, construction, agriculture,

    vehicle repair and in–plant operations. Outstanding resistance to heat and ozone. Suitable for light agricultural spraying,
    such as dilute solutions of herbicides.
    TEMPERATURE: –40°F to +200°F (–40°C to +93°C) continuous service.
    CONSTRUCTION: Tube: Type P (EPDM). Black.


    Reinforcement: Synthetic, high tensile textile cord.
    Cover: Type P (EPDM). All sizes through 1/2" are perforated.
    Design Factor: 3:1
    COUPLINGS: 19 (up through 1/2" only), 1, 3 or 4, (up through 1/2" with 20 brass ferrules, up through 1" with bands), 72 Gates Power
    Crimp    ® or 75 Gates GLX®. Reference the Hose Coupling Section.
    STANDARDS: Tube: ARPM (Class C) Limited oil–resistance.
    Cover: ARPM (Class C) Limited oil–resistance.
